Chip numbers starting with 808

nr name cat description manufacturer
808 AD808 rcvr Fiber Optic Receiver consumin 400 mW and operates from a single power supply at either +5V or +5.2V, data AD
8080 i8080A mpu 8-Bit MPU, pinout, 8080A-Card Harris, Intel*
8081 S-8081b timer IC*, pinout seik
8085 mpu 8-Bit MPU (=8080+), pinout, 8085A-Card Intel*
8085 8085 ~ pinout
8085 80C85-AP2 mpu CPU order from Barend
8085 MSM80C85A mpu Oki
8085 i8085 mpu MPU MPU Intel $1
80851 80C851 mcu 128*8 RAM 2 timers 4 ports 12 MHz 256 Byte EPROM* Philips
80851 80C851 mcu MCU (=8051+) 128*8 RAM, 64Kx*8 ROM, 8051+256B EEPROM, DIP40 Philips
80851 P80C851 mcu 8-bit CMOS* MCU DIL40 Philips
80851 S80C851 mcu 8-bit CMOS* MCU DIL40 Philips
8086 CD80C86 mpu 40 CDIP 0+70C 5.0V 5.0MHz 16 bit MPU Harris $19/1K
8086 CD80C86-2 mpu 40 CDIP 0+70C 5.0V 8.0MHz 16 bit MPU Harris $25/1K
8086 CP80C86 mpu 40 PDIP 0+70C 5.0V 5.0MHz 16 bit MPU Harris $10/1K
8086 CP80C86-2 mpu 40 PDIP 0+70C 5.0V 8.0MHz 16 bit MPU Harris $13/1K
8086 CS80C86 mpu 44 PLCC 0+70C 5.0V 5.0MHz 16 bit MPU Harris $11/1K
8086 CS80C86-2 mpu 44 PLCC 0+70C 5.0V 8.0MHz 16 bit MPU Harris $14/1K
8086 ID80C86 mpu 40 CDIP -40+85C 5.0V 5.0MHz 16 bit MPU Harris $27/1K
8086 ID80C86-2 mpu 40 CDIP -40+85C 5.0V 8.0MHz 16 bit MPU Harris $35/1K
8086 IP80C86 mpu 40 PDIP -40+85C 5.0V 5.0MHz 16 bit MPU Harris $14/1K
8086 IP80C86-2 mpu 40 PDIP -40+85C 5.0V 8.0MHz 16 bit MPU Harris $18/1K
8086 IS80C86 mpu 44 PLCC -40+85C 5.0V 5.0MHz 16 bit MPU Harris $17/1K
8086 IS80C86-2 mpu 44 PLCC -40+85C 5.0V 8.0MHz 16 bit MPU Harris $22/1K
8086 MD80C86-2/883 mpu CMOS* 16 bit CPU-MIL-8MHz- 40 Pin CDIP Harris $128/1K
8086 MD80C86-2/B mpu CMOS* 16 bit CPU-MIL-8MHz- 40 Pin CDIP Harris $112/1K
8086 MD80C86/B mpu CMOS* 16 bit CPU-MIL-5MHz- 40 Pin CDIP Harris $98/1K
8086 MR80C86-2/883 mpu CMOS* 16 bit CPU-MIL-8MHz- 44 Pin LCC Harris $293/1K
8086 MR80C86-2/B mpu CMOS* 16 bit CPU-MIL-8MHz- 44 Pin LCC Harris $255/1K
8086 MR80C86/B mpu CMOS* 16 bit CPU-MIL-5MHz- 44 Pin LCC Harris $135/1K
8086 MSM80C86A mpu Oki
8086 i8086 mpu 16-Bit MPU from the 80x86-family, pinout, I-set, Gif, Card, amd.com/..(CPU's), amd.com/..(MCU's), Offerman/.., pinout Harris, Intel*, many $1.55
8086883 MD80C86/883 mpu CMOS* 16 bit CPU-MIL-5MHz- 40 Pin CDIP Harris $112/1K
8086883 MR80C86/883 mpu CMOS* 16 bit CPU-MIL-5MHz- 44 Pin LCC Harris $155/1K
8087 fpu Numeric data processor, pinout Intel*
8088 mpu 16-Bit 8086 MPU with 8-Bit Data Bus, pinout, Card Harris, Intel*, many
8088 CD80C88 mpu 40 CDIP 0+70C 5.0V 5.0MHz 8/16 bit MPU Harris $15/1K
8088 CD80C88-2 mpu 40 CDIP 0+70C 5.0V 8.0MHz 8/16 bit MPU Harris $20/1K
8088 CP80C88 mpu 40 PDIP 0+70C 5.0V 5.0MHz 8/16 bit MPU Harris $8/1K
8088 CP80C88-2 mpu 40 PDIP 0+70C 5.0V 8.0MHz 8/16 bit MPU Harris $10/1K
8088 CS80C88 mpu 44 PLCC 0+70C 5.0V 5.0MHz 8/16 bit MPU Harris $9/1K
8088 CS80C88-2 mpu 44 PLCC 0+70C 5.0V 8.0MHz 8/16 bit MPU Harris $12/1K
8088 HCP80C88 mpu MPU CMOS* Harris $1.00
8088 ID80C88 mpu 40 CDIP -40+85C 5.0V 5.0MHz 8/16 bit MPU Harris $22/1K
8088 ID80C88-2 mpu 40 CDIP -40+85C 5.0V 8.0MHz 8/16 bit MPU Harris $29/1K
8088 IP80C88 mpu 40 PDIP -40+85C 5.0V 5.0MHz 8/16 bit MPU Harris $11/1K
8088 IP80C88-2 mpu 40 PDIP -40+85C 5.0V 8.0MHz 8/16 bit MPU Harris $15/1K
8088 IS80C88 mpu 44 PLCC -40+85C 5.0V 5.0MHz 8/16 bit MPU Harris $14/1K
8088 IS80C88-2 mpu 44 PLCC -40+85C 5.0V 8.0MHz 8/16 bit MPU Harris $18/1K
8088 IS80C88-296 mpu IS80C88-2 IN tape and reel Harris $18/1K
8088 IS80C88-2X96 mpu IS80C88-2 IN tape and reel Harris $18/1K
8088 MD80C88-2/883 mpu CMOS* 8/16 bit CPU-MIL-8MHz- 40 Pin DIP Harris $151/1K
8088 MD80C88-2/B mpu CMOS* 8/16 bit CPU-MIL-8MHz- 40 Pin CDIP Harris $151/1K
8088 MD80C88/B mpu CMOS* 8/16 bit CPU-MIL-5MHz- 40 Pin CDIP Harris $110/1K
8088 MR80C88-2/883 mpu CMOS* 8/16 bit CPU-MIL-8MHz- 44 Pin LCC Harris $210/1K
8088 MR80C88-2/B mpu CMOS* 8/16 bit CPU-MIL-8MHz- 44 Pin LCC Harris $210/1K
8088 MR80C88/B mpu CMOS* 8/16 bit CPU-MIL-5MHz- 44 Pin LCC Harris $151/1K
8088 MSM80C88A mpu Oki
8088 i8088 mpu MPU Intel $2.20
8088883 MD80C88/883 mpu CMOS* 8/16 bit CPU-MIL-5MHz-DIP Harris <$1/1K
8088883 MR80C88/883 mpu CMOS* 8/16 bit CPU-MIL-5MHz- 44 Pin LCC Harris $151/1K
8089 periph I/O* processor Intel



Other sites where you can search on chip number

www.chipdocs.com/ Very good!
www.icmaster.com/ Registration is needed in advance. Will be closed spring 2002.
www.questlink.com/ Registration is needed before you can download datasheets. Chips can sometimes be ordered via Arrow/Avnet.
www.elisnet.or.jp/ In Japanese only.

For more data about the above WWW sites and for more information sites.
www.findchips.com/ Do a search at 20+ distributors at once!
www.netcomponents.com/ Do a search for scarce chips at many brokers at once!


To get chips listed

When you're the webmaster/database manager of an IC* manufacturer and you'd like to get your IC*'s listed on sites like these (including the ICMaster) but don't want to deal with all sites separately, a couple of us are trying to set up a system whereby the IC* manufacturers just put a comma seperated value's (.csv) file on their site with all of their data and we all read that regurarly and work the data into our databases of chips. Please visit www.elip.org/ for more details. One of the manufacturers already cooperating is ON Semiconductor (formerly part of Motorola).
